XG3165C
XGMA • Grader
The XG3165C is a versatile 16.5-ton motor grader designed for road construction, site preparation, mining support, and maintenance applications. Powered by a reliable 180 HP Cummins engine and equipped with a 3,660 mm moldboard, it delivers precise grading performance, smooth control, and excellent maneuverability across various jobsite conditions. The electro-hydraulic transmission and 360° blade rotation provide flexibility for shaping, leveling, ditching, and road maintenance operations.
Starting from
Call our sales team for pricing
Class
180 HP class
Blade Length / Width
3,660 mm
Engine Power (HP)
180 HP
Operating Weight
16,500 kg
Technical Specifications
Comprehensive engineering data for operational planning.
General
Class180 HP class
Transmission / GearboxElectro-hydraulic gear shift
Dimensions & Weights
Operating Weight16,500 kg
Engine
Engine MakeDCEC
Engine Model6BTAA5.9-C180
Engine Power (kW)132 kW
Engine Power (HP)180 HP
Rated Engine Speed2,200 rpm
Performance
Power-to-Weight8 kW/T
Grader Specifications
Blade Length / Width3,660 mm
Blade Height / Chord Height610 mm
Blade Rotation360°
Blade Tilt Angle90°
Original Headline Specs
Reliable Cummins Power132 kW (180 HP) Engine
Reliable Cummins Power (description)Provides dependable performance, fuel efficiency, and strong pulling power for demanding grading applications.
Precision Grading Control3,660 mm Blade Width
Precision Grading Control (description)Delivers accurate leveling and surface finishing with excellent material coverage per pass.
Full Blade Versatility360° Rotation • 90° Tilt
Full Blade Versatility (description)Enables efficient ditching, slope cutting, shoulder maintenance, and complex grading operations.
Smooth Electro-Hydraulic TransmissionElectro-Hydraulic Gear Shift
Smooth Electro-Hydraulic Transmission (description)Improves operator comfort, shifting efficiency, and machine responsiveness during continuous operation.
Need the Full Technical Catalog?
Download the complete product catalog for detailed specifications, configurations, and compatibility data for your engineering team.
