XG3200N
XGMA • Grader
The XG3200N is a heavy-duty motor grader engineered for highway construction, mining roads, site preparation, and large-scale earthmoving projects. Powered by a 160 kW SDEC engine and equipped with a 4,270 mm moldboard, it delivers excellent grading precision, strong traction, and reliable performance for demanding infrastructure applications. Its electro-hydraulic transmission and full blade articulation provide smooth operation and high productivity across various terrain conditions.
Starting from
Call our sales team for pricing
Class
220 HP class
Blade Length / Width
4,270 mm
Engine Power (HP)
220 HP
Operating Weight
20,000 kg
Technical Specifications
Comprehensive engineering data for operational planning.
General
Class220 HP class
Transmission / GearboxElectro-hydraulic gear shift
Dimensions & Weights
Operating Weight20,000 kg
Engine
Engine MakeSDEC
Engine ModelSC9D220G2
Engine Power (kW)160 kW
Engine Power (HP)220 HP
Rated Engine Speed2,200 rpm
Performance
Power-to-Weight8 kW/T
Grader Specifications
Blade Length / Width4,270 mm
Blade Height / Chord Height610 mm
Blade Rotation360°
Blade Tilt Angle90°
Original Headline Specs
Powerful SDEC Engine160 kW @ 2,200 rpm
Powerful SDEC Engine (description)Delivers strong grading power, reliable performance, and efficient operation for heavy-duty construction projects.
Wide Moldboard Coverage4,270 × 610 mm Blade
Wide Moldboard Coverage (description)Covers more ground per pass, improving grading efficiency and reducing project completion time.
Full Blade Flexibility360° Rotation • 90° Tilt
Full Blade Flexibility (description)Enables precise slope cutting, ditching, road shaping, and fine grading applications.
Electro-Hydraulic TransmissionElectro-Hydraulic Gear Shift
Electro-Hydraulic Transmission (description)Provides smoother shifting, improved machine control, and enhanced operator comfort.
Need the Full Technical Catalog?
Download the complete product catalog for detailed specifications, configurations, and compatibility data for your engineering team.
