Fleet>Forklift>XG525B-LAA5

XG525B-LAA5

Name: XG525B-LAA5
Brand: XGMA
Availability: InStock

XGMA • Forklift

The XGMA XG525B-LAA5 is a 2.5-ton lithium battery forklift designed to deliver clean, quiet, and efficient material handling for warehouses, logistics centers, manufacturing facilities, and distribution operations. Equipped with a high-performance AC drive system and maintenance-free lithium battery technology, it provides fast acceleration, smooth lifting performance, and extended operating time with rapid charging capability. Its compact design, ergonomic operator compartment, and responsive steering ensure excellent maneuverability in confined spaces while reducing operator fatigue. Built for maximum efficiency and low operating costs, the XG525B-LAA5 offers an environmentally friendly solution for modern indoor and outdoor material handling applications.

Starting from

Call our sales team for pricing

Class

2.5 T class

Fuel / Power Type

Lithium Battery

Engine Power (kW)

11.1 kW

Technical Specifications

Comprehensive engineering data for operational planning.

General

Class2.5 T class

Dimensions & Weights

Payload / Rated Load2,500 kg

Engine

Engine Power (kW)11.1 kW

Engine Power (HP)15 HP

Fuel / Power TypeLithium Battery

Performance

Max. Travel Speed13 km/h

Gradeability15%

Forklift Specifications

Load Center Distance500 mm

Lifting Speed (Loaded)260 mm/s

Battery240 Ah

Battery Voltage50.4 V

Original Values (as stated)

Battery Voltage50.4 V

Additional Specs

Model NameCPD25

Max. Unloaded Speed15 km/h

Unloaded Lifting Speed460 mm/s

Max. Loaded Traction13.5 kN

Max. Unloaded Traction12.5 kN

Work Drive Motor12 kW

Motor TypeFull AC Power System

Original Headline Specs

Rated Capacity2,500 kg

Rated Capacity (description)Designed for everyday warehouse and logistics operations, the XG525B-LAA5 safely handles pallets, packaged goods, and industrial materials while maintaining excellent lifting stability and maneuverability.

Lithium Battery System50.4 V / 240 Ah

Lithium Battery System (description)The maintenance-free lithium battery delivers rapid charging, longer service life, consistent power output, and reduced operating costs compared with conventional lead-acid batteries.

Full AC Drive System11.1 kW Drive • 12 kW Hydraulic Motor

Full AC Drive System (description)Equipped with high-efficiency AC motors, the forklift provides smooth acceleration, responsive hydraulic operation, and reliable performance with minimal maintenance requirements.

Efficient Travel Performance13 / 15 km/h (Loaded / Unloaded)

Efficient Travel Performance (description)A maximum travel speed of up to 15 km/h enables efficient transportation between storage and loading areas, improving productivity throughout daily operations.

Need the Full Technical Catalog?

Download the complete product catalog for detailed specifications, configurations, and compatibility data for your engineering team.
