XG612H
XGMA • Compactor
The XG612H is a versatile 12-ton single drum vibratory roller engineered for highway construction, industrial sites, and large-scale earthwork projects. With increased drum weight and static line load, it provides deeper compaction and higher productivity across various ground conditions.
Starting from
Call our sales team for pricing
Class
12 T class
Drum Width
2,130 mm
Static Linear Load
333 N/cm
Engine Power (kW)
112 kW
Technical Specifications
Comprehensive engineering data for operational planning.
General
Class12 T class
Dimensions & Weights
Operating Weight12,000 kg
Overall Length6,194 mm
Overall Width2,270 mm
Overall Height3,170 mm
Engine
Engine MakeCummins
Engine Model6BTA5.9-C150
Engine Power (kW)112 kW
Engine Power (HP)150 HP
Rated Engine Speed2,400 rpm
Performance
Power-to-Weight9.3 kW/T
Compactor Specifications
Drum Width2,130 mm
Drum Diameter1,550 mm
Static Linear Load333 N/cm
Front Drum Weight7,200 kg
Original Headline Specs
Enhanced Compaction Force12,000 kg Operating Weight
Enhanced Compaction Force (description)Provides greater compaction energy for improved density and fewer passes.
Heavy Front Drum7,200 kg Drum Weight
Heavy Front Drum (description)Generates stronger vibration transfer for deeper compaction performance.
High Static Line Load333 N/cm
High Static Line Load (description)Delivers superior ground penetration for base layers and subgrade preparation.
Proven Powertrain112 kW Cummins Engine
Proven Powertrain (description)Ensures reliable operation and strong performance in demanding environments.
