Fleet>Excavator>XG809F

XG809F

Name: XG809F
Brand: XGMA
Availability: InStock

XGMA • Excavator

The XGMA XG809F is a powerful 8.2-ton crawler excavator designed for high productivity in construction, infrastructure, quarry, and utility projects. Powered by the proven Yanmar 4TNV98T diesel engine producing 56.2 kW, the XG809F combines strong digging performance with excellent fuel efficiency and reliable hydraulic operation. Its 0.32 m³ bucket and reinforced boom structure enable efficient excavation, trenching, and material handling in demanding working environments. The durable crawler undercarriage provides outstanding stability and traction across uneven terrain, while the ergonomic operator cabin enhances comfort and visibility during extended working hours. Designed for long service life and easy maintenance, the XG809F supports a variety of hydraulic attachments, making it a versatile and cost-effective solution for contractors seeking dependable performance and maximum jobsite productivity.

Starting from

Call our sales team for pricing

Class

8.2 T class · Tracked

Bucket Capacity

0.32 m³

Operating Weight

8,200 kg

Engine Power (kW)

56.2 kW

Technical Specifications

Comprehensive engineering data for operational planning.

General

Class8.2 T class · Tracked

UndercarriageTracked

Dimensions & Weights

Operating Weight8,200 kg

Engine

Engine MakeYanmar

Engine ModelYANMAR 4TNV98T

Engine Power (kW)56.2 kW

Engine Power (HP)75 HP

Rated Engine Speed2,200 rpm

Performance

Max. Travel Speed5.1 km/h

Gradeability70%

Fuel Tank Capacity130 L

Power-to-Weight6.9 kW/T

Excavator Specifications

Bucket Capacity0.32 m³

Breakout / Digging Force52 kN

Boom Length3,710 mm

Arm Length1,650 mm

Swing Speed10 rpm

Ground Pressure30 kPa

Hydraulic Tank Capacity90 L

Original Values (as stated)

Travel Speed5.1 km/h - 2.7 km/h

Original Headline Specs

Machine Class8.2 Ton Crawler Excavator

Machine Class (description)The XG809F belongs to the 8.2-ton excavator class, offering excellent stability, digging capability, and lifting performance for medium-duty construction, infrastructure, and earthmoving projects.

Engine Power56.2 kW Yanmar 4TNV98T Diesel Engine

Engine Power (description)Powered by a turbocharged Yanmar engine producing 56.2 kW, the XG809F delivers strong hydraulic performance, reliable power output, and excellent fuel efficiency for continuous heavy-duty operation.

Bucket Capacity0.32 m³

Bucket Capacity (description)Equipped with a 0.32 m³ bucket, the XG809F efficiently handles excavation, trenching, and material loading tasks while improving productivity through faster work cycles and optimized digging performance.

Bucket Digging Force52 kN

Bucket Digging Force (description)With a powerful bucket digging force of 52 kN, the XG809F easily penetrates compacted soil and challenging materials, delivering consistent excavation performance and higher productivity in demanding jobsite conditions.

Need the Full Technical Catalog?

Download the complete product catalog for detailed specifications, configurations, and compatibility data for your engineering team.
