Fleet>Excavator>XG839EL

XG839EL

Name: XG839EL
Brand: XGMA
Availability: InStock

XGMA • Excavator

The XGMA XG839EL is a premium 37.5-ton crawler excavator engineered for maximum productivity in mining, quarrying, heavy construction, and large-scale earthmoving applications. Powered by a reliable 212 kW Isuzu 6HK1X diesel engine, it delivers exceptional hydraulic performance, high fuel efficiency, and dependable power for continuous heavy-duty operation. Featuring a 1.6–1.9 m³ bucket, reinforced boom and arm, and a rugged crawler undercarriage, the XG839EL provides outstanding digging force, high loading efficiency, and superior stability on demanding jobsites. Its spacious operator cabin offers excellent visibility, ergonomic controls, and a comfortable working environment, while the simplified maintenance layout helps maximize machine uptime. Designed for durability and performance, the XG839EL is the ideal solution for contractors and mining operators seeking powerful excavation capability, long-term reliability, and lower total operating costs.

Starting from

Call our sales team for pricing

Class

37.5 T class · Tracked

Bucket Capacity

1.6 m³

Operating Weight

37,500 kg

Engine Power (kW)

212 kW

Technical Specifications

Comprehensive engineering data for operational planning.

General

Class37.5 T class · Tracked

UndercarriageTracked

Dimensions & Weights

Operating Weight37,500 kg

Engine

Engine MakeIsuzu

Engine Model6HK1X

Engine Power (kW)212 kW

Engine Power (HP)284 HP

Rated Engine Speed2,000 rpm

Performance

Max. Travel Speed5.2 km/h

Gradeability70%

Fuel Tank Capacity595 L

Power-to-Weight5.7 kW/T

Excavator Specifications

Bucket Capacity1.6 m³

Breakout / Digging Force256 kN

Boom Length6,470 mm

Arm Length2,900 mm

Swing Speed8.5 rpm

Ground Pressure70.8 kPa

Hydraulic Tank Capacity310 L

Original Values (as stated)

Travel Speed5.2 km/h - 3.3 km/h

Additional Specs

Bucket Capacity1.6-1.9 m³

Bucket Digging Force256 KN

Original Headline Specs

Machine Class37.5 Ton Crawler Excavator

Machine Class (description)As one of XGMA's largest crawler excavators, the XG839EL is built for high-production mining, quarrying, and major infrastructure projects where maximum stability, lifting capability, and continuous performance are essential.

Engine Power212 kW Isuzu 6HK1X Diesel Engine

Engine Power (description)Powered by the proven Isuzu 6HK1X engine delivering 212 kW at 2,000 rpm, the XG839EL provides dependable power, excellent fuel efficiency, and responsive hydraulic performance for demanding excavation applications.

Bucket Capacity1.6–1.9 m³

Bucket Capacity (description)Available with bucket capacities from 1.6 to 1.9 m³, the XG839EL is designed for high-volume excavation and material loading, increasing productivity while reducing cycle times in large-scale earthmoving operations.

Bucket Digging Force256 kN ISO

Bucket Digging Force (description)Delivering an impressive ISO-rated bucket digging force of 256 kN, the XG839EL provides outstanding breakout performance for hard rock, compacted soil, and heavy excavation tasks, ensuring maximum productivity in the toughest working conditions.

Need the Full Technical Catalog?

Download the complete product catalog for detailed specifications, configurations, and compatibility data for your engineering team.
